BROOK CROMPTON Motor



นำเข้า จำหน่าย ขาย ตัวแทนจำหน่ายมอเตอร์  BROOK CROMPTON Motor

                                                                       T- Series motors

63 to 355

TP2 Series High Efficiency Motor

New IE2 efficiency Standard

EEx d/de flamproof motors

90-315L

W-SERIES (High Efficiency Aluminium Motors)

W high efficiency aluminium motors 63 to 200L

WP - SERIES (Premium Efficiency Motors)

WP premium efficiency motors 80 t 355L

​BROOK A-DA100LA

BROOK B-DA71MB

BROOK B-DA100LA BROOK P-DA132SB

BROOK A-DA112MA BROOK B-DA80MA BROOK B-DA112MA BROOK P-DA160MA

BROOK A-DA132SA BROOK B-DA80MB BROOK B-DA132SA BROOK P-DA80MA

BROOK A-DA132SB BROOK B-DA90LA BROOK B-DA132SB BROOK P-DA80MB

BROOK A-DA80MA BROOK B-DA90SA BROOK B-DA63MA BROOK P-DA90LA

BROOK A-DA80MB BR​OOK P-DA100LA BROOK B-DA63MB BROOK P-DA90SA

BROOK A-DA90LA BROOK P-DA112MA BROOK B-DA71MA

BROOK A-DA90SA BROOK P-DA132SA

Performance data BROOK CROMPTON T Series

2 Pole -50 HZ 3000RPM

Motor	kW	Full Load Speed	INL 400 V	IFL 380 V	IFL 400V	IFL 415
		rpm	amps	amps	amps	amps
T-DF80MA	0.75	2840	0.9	1.8	1.7	1.7
T-DF80MB	1.1	2845	1.2	2.6	2.5	2.4
T-DF90SA	1.5	2850	1.4	3.5	3.3	4.4
T-DF90LA	2.2	2850	2	4.9	4.6	5.8
T-DF100LA	3	2860	2.2	6.3	6	7.5
T-DF112MA	4	2870	2.4	8.2	7.8	10.3
T-DF112MB	5.5	2890	3.3	11.3	10.7	10.1
T-DF132SA	5.5	2900	3.8	11.1	10.5	13.6
T-DF132SB	7.5	2915	4.5	14.9	14.1	20
T-DF132MA	11	2915	5.9	21.8	20.7	19.5
T-DF160MA	11	2930	6.2	21.2	20.2	26.2
T-DF160MB	15	2930	7.6	28.6	27.2	31.8
T-DF160LA	18.5	2935	8.1	34.7	33	37.6
T-DF180MA	22	2940	11	41	39	50.7
T-DF200LA	30	2950	14.5	55.4	52.6	62.2
T-DF200LB	37	2955	17.3	67.9	64.5	75
TU-DF225M	45	2960	20.5	82.1	78	0.2
TU-DF250M	55	2965	27.9	99.8	94.8	91.4
TU-DF250M	75	2965	35	136.1	129.3	124.7
TU-DF280S	75	2965	33.2	135.3	128.5	123.9
TU-DF280MA	90	2970	35.8	160	152	128.5
TU-DF280MB	110	2970	36.4	195.6	185.8	152
TU-DF315SA	110	2975	45.5	195.4	185.6	185.8
TU-DF315MA	132	2980	56	233.2	221.6	185.6
TU-DF315LA	160	2980	61	279.3	265.4	221.6
TU-DF315LB	200	2980	61.1	348.4	331	265.4
TU-DF355M	250	2985	108	433.7	412	331
TU-DF355L	315	2985	129	545.3	518	412

4 Pole -50 Hz 1500 RPM

Motor	kW	Full Load Speed	INL 400 V	IFL 380 V	IFL 400V	IFL 415
		rpm	amps	amps	amps	amps
T-DF80MA	0.55	1410	1	1.6	1.5	14
T-DF80MB	0.75	1415	1.3	2.1	2	1.9
T-DF90SA	1.1	1405	1.8	2.8	2.7	2.6
T-DF90LA	1.5	1410	2	3.7	3.5	3.4
T-DF100LA	22	1415	2.7	5.1	4.8	4.7
T-DF112MA	3	1420	3.3	6.7	6.4	6.2
T-DF112MB	4	1440	4.1	8.8	8.4	9.1
T-DF132SA	5.5	1450	5.4	11.7	11.2	10.8
T-DF132SB	7.5	1450	6.1	15.6	14.8	14.3
T-DF132MA	11	1450	7.9	22.9	21.7	20.9
T-DF160MA	11	1460	8.3	22.5	21.4	20.6
T-DF160MB	15	1460	11.1	30	28.5	27.5
T-DF160LA	18.5	1465	12.5	36.3	34.5	33.3
T-DF180MA	22	1470	14.7	42.9	40.8	39.3
T-DF200LA	30	1475	17.5	58	55.1	53.1
T-DF200LB	37	1480	22.1	70.2	66.7	64.3
TU-DF225M	45	1480	24.5	85	80	77.8
TU-DF250M	55	1480	32.1	103.3	798.1	94.6
TU-DF250M	75	1480	36.2	140.8	133.8	129
TU-DF280S	75	1480	36.5	139.9	132.9	128.1
TU-DF280MA	90	1485	43.6	167.4	159	153.3
TU-DF280MB	110	1480	52.4	204.6	194.4	187.3
TU-DF315SA	110	1485	51.2	201	190.9	184
TU-DF315MA	132	1485	64.8	240.4	228.4	220.1
TU-DF315LA	160	1489	79.2	287.8	273.4	263.6
TU-DF315LB	200	1489	102	359.8	341.8	329.4
TU-DF355M	250	1490	104	443.3	421.2	405.9
TU-DF355L	315	1490	136	558.6	530.7	511.5

6 pole -50 Hz 1000 RPM

Motor	kW	Full Load Speed	INL 400 V	IFL 380 V	IFL 400V	IFL 415
		rpm	amps	amps	amps	amps
T-DF80MA	0.37	915	0.9	1.3	1.2	1.2
T-DF80MB	0.55	915	1.1	1.8	1.7	1.6
T-DF90SA	0.75	920	1.5	2.3	2.2	2.1
T-DF90LA	1.1	925	2	3.2	3	2.9
T-DF100LA	1.5	925	2.5	4	3.8	3.7
T-DF112MA	2.2	935	2.9	5.6	5.3	5.1
T-DF132SA	3	960	4.1	7.4	7	6.8
T-DF132MA	4	960	5.1	9.8	9.3	8.9
T-DF132MB	5.5	960	7.2	12.9	12.3	11.8
T-DF160MA	7.5	965	7.5	17.2	16.3	15.8
T-DF160LA	11	970	10.1	24.5	23.3	22.4
T-DF180LA	15	970	13.5	31.6	30	28.9
T-DF200LA	18.5	975	16.1	38.6	36.6	35.3
T-DF200LB	22	975	16.5	44.7	42.5	41
TU-DF225M	30	980	20.4	59.3	56.3	54.3
TU-DF250M	37	980	23.7	71.1	67.5	65.1
TU-DF280S	45	980	26.1	85.9	81.7	78.7
TU-DF280MA	55	980	29	104.7	995	95.9
TU-DF280MB	75	980	47.8	142.8	135.6	130.7
TU-DF315SA	75	985	44.5	141.7	134.6	129.8
TU-DF315MA	90	985	50	169.5	161	155.2
TU-DF315LA	110	990	55.2	206.7	196.4	189.3
TU-DF315LB	132	990	69	244.7	232.5	224.1
TU-DF355MA	160	990	91	292.3	277.7	267.7
TU-DF355MB	200	990	91.5	365.4	347.1	334.6
TU-DF355L	250	990	104	456.8	433.9	418.2

8 Pole -50 Hz750 RPM

Motor	kW	Full Load Speed	INL 400 V	IFL 380 V	IFL 400V	IFL 415
		rpm	amps	amps	amps	amps
T-DF80MA	0.18	680	0.7	0.9	0.8	0.8
T-DF80MB	0.25	690	1	1.2	1.1	1.1
T-DF90SA	0.37	700	1.1	1.5	1.4	1.4
T-DF90LA	0.55	700	1.7	2.2	2.1	2
T-DF100LA	0.75	700	2	2.4	2.3	2.2
T-DF100LB	1.1	700	2.5	3.3	3.2	3
T-DF112MA	1.5	700	3	4.4	4.2	4
T-DF112MB	2.2	700	3.6	6.5	6.1	5.9
T-DF132S	2.2	705	3.9	6	5.7	5.5
T-DF132MA	3	705	4.4	7.9	7.5	7.2
T-DF132MB	4	706	5.8	10.5	10	9.6
T-DF160MA	4	710	6	10.3	9.8	9.4
T-DF160MB	5.5	715	7.7	13.6	12.9	12.5
T-DF160L	7.5	720	9.5	17.8	16.9	16.3
T-DF180L	11	730	12.4	25.1	23.9	23
T-DF200L	15	730	15.5	34.1	32.4	31.2
TU-DF225S	18.5	731	20.3	41.1	39	37.6
TU-DF225M	22	735	20.8	47.4	45	43.4
TU-DF250M	30	735	28.6	63.4	60.2	58.1
TU-DF280S	37	735	30.5	77.8	73.9	71.2
TU-DF280MA	45	740	36	94.1	89.4	86.1
TU-DF280MA	55	740	41.8	115	109.2	105.3
TU-DF315SA	55	740	43.2	111.2	105.6	101.8
TU-DF315MA	75	740	49.5	151.3	143.7	138.5
TU-DF315LA	90	740	67	177.8	168.9	162.8
TU-DF315LB	110	740	75.6	216.8	206	198.5
TU-DF355MA	132	740	87.3	261	248	239
TU-DF355MB	160	743	105.8	314.7	299	288.2
TU-DF355LA	200	743	112	387.4	368.1	354.8
